Home > Android/Linux Box > ZIDOO X9S Smart TV box 2G/16G Android 6.0 + OpenWRT(NAS) Realtek RTD1295 2.4G&5.8G WIFI Bluetooth4.0 1000M LAN Media Player

Android/Linux Box > ZIDOO X9S Smart TV box 2G/16G Android 6.0 + OpenWRT(NAS) Realtek RTD1295 2.4G&5.8G WIFI Bluetooth4.0 1000M LAN Media Player

ZIDOO X9S Smart TV box 2G/16G Android 6.0 + OpenWRT(NAS) Realtek RTD1295 2.4G&5.8G WIFI Bluetooth4.0 1000M LAN Media Player

ZIDOO X9S Smart TV box 2G/16G Android 6.0 + OpenWRT(NAS) Realtek RTD1295 2.4G&5.8G WIFI Bluetooth4.0 1000M LAN Media Player

ZIDOO X9S Android TV BOX Android 6.0 + OpeGnWRT(NAS) Realtek RTD1295 2G/16G Dual band 802.11ac WIFI 2.4&5.8G Bluetooth4.0 1000M LAN Media Player



ZIDOO X9S android 6.0 TV box 1



Specification

Model

X9S

Material

Space Aluminium

Shell

Aviation Aluminum alloy case in smoke-colored

OS

Android 6.0 + OpenWRT(NAS) dual system run simultaneously

CPU

Realtek RTD1295 ARM Cortex-A53 Quad-Core with floating-point unit and NEON SIMD engine embedded

GPU

ARM T820 MP3(3-core)

Memory

2GB DDR3

Internal Storage

16GB eMMC

Wifi Connectivity

IEEE 802.11a/b/g/n, 802.11AC,4.900 GHz ~ 5.845 GHz (5.0 GHz ISM Band) RTK8821 dual-band WIFI

Ethernet

1*RJ-45 Ethernet Jack (10/100/1000Mbps)

Bluetooth

BT4.0

Video decode

 HDR, 10-bit HEVC/H.265 up to 4K @ 60fps, VP9 up to 4K @ 60 fps, H.264 up to 4K @ 24 fps, automatic frame rate switching

Audio decode

Support HD audio(7.1ch) decode and passthrough Redesigned Native player,Blu-ray better compatibility,Powerful subtitles ,Support MVC ISO,MVC MKV. Built in ZDMC(Base on kodi 16.0)

USB

1 * USB3.0
2 * USB2.0

Power

12V/3A

other interface

1 * TF card reader SD card interface . Support 1GB/2GB/4GB/8GB/16GB/32GB
1 * IR receiver
1 * Composite video and audio port (Cvbs output)
1 * S/SPDIF (2CH, 5.1CH)
1 * SATA3.0
1 * VFD display

What's in the box:

1 x TV box
1 x Romote control
1 x HDMI cable
1 x Power adapter
1 x User manual
1 x SATA cable





Features & Pictures:

ZIDOO X9S 1ZIDOO X9S 2

The ZIDOO X9S features a RTD1295 processor, fully supporting Premium 4K UHD contents with a powerful 64bit



CPU and Mali-T820 GPU combination in place to handle 4K graphics and offers strikingly realistic pictures.  It supports a wider color spectrum



(BT.2020) and a 10-bit color, amounting to 1.06 billion colors, instead of the 16 million offered by older 8-bit color technologies, therefore,



thegradations between shades and different tones on onscreen content present a far greater degree of realism.



ZIDOO X9S 3

The ARM® Mali™-T820, equivalent to an Octa-core Mali 450,

provides the optimal blend of features and efficiency to deliver rich user interfaces and compelling content.



ZIDOO X9S 4



2G+16G



2GB DDR3 RAM makes bigger games run smoothly and the utilization of eMMC memory offers an array of benefits in terms of performance securityand reliability, resulting in a richer end-user experience.

ZIDOO X9S 5

HDMI 2.0a interface supporting HDR transmition



HDMI 2.0a added HDR(High-Dynamic Range) support based on HDMI 2.0.  HDR provided far more detail of picture and expands the dynamic range, to get a true vision effect.Additionally, ZIDOO X9S supports both decoding and encoding of 4K@60P HEVC(h.265)10bit.

ZIDOO X9S 6

ZIDOO X9S 7

ZIDOO X9S 8



Multi channels decoding and passthrough supported, Support Dolby Digital and DTS-HD passthrough and downmix

ZIDOO X9S 9



Play everything you want,Such as HTML5,MKV, MP4,BD ISO ,3D MVC(ISO and MKV),VP9, etc..

ZIDOO X9S 10



With the Gigabit Ethernet and 802.11ac dual band WIFI supporting 2.4G and 5G, 5dB Double antenna.ZIDOO X9S can provide reliable network access with high data rates.

ZIDOO X9S 11



Additionally, the Bluetooth 4.0 module allows connection to your BT speakers, Keyboard, Mouse and many more.



12

ZIDOO X9S 12

HDMI IN



Zidoo X9S supports HDMI-IN with the Picture in Picture(PIP) function,record function.stream to UDP function.



A RTC battery is insidemade it the best solution for Digital Signage



ZIDOO X9S 13

ZIDOO X9S 14



The Powerful ZIUI



ZIUI is more than a launcher, it is a series of components developed by the ZIDOO staff over several years, which includes a file manager, a NAS kit,a feature-rich player with powerful subtitle supports and an OTA service based on the global CDN cloud.



ZIDOO X9S 15

ZIDOO X9S 16



The ZIDOO X9S is based ADNROID 6.0supporting built-in applications such as GOOGLE PLAY, KODI, YouTube, Netflix, Skype and many more.

A great box with fantastic compatibilities to meet the most demanding entertainment expectations!



ZIDOO X9S 17

Comprehensive interfaces provide different levels of interactivity.



The ZIDOO X9S sports various interfaces, including SATA 3.0, USB 3.0, Gigabit Network, Optical SPDIF, Composite Audio, HDMI 2.0A, allowing limitless connectivity to external devices.



ZIDOO X9S 18



ZIDOO attaches great importance to its product excellence, using the highest quality electronic components and complying with environmental friendly standard all over the world. Quality is the Lifeblood of an Enterprise.



ZIDOO X9S 19





ZIDOO X9S 21ZIDOO X9S 20ZIDOO X9S 22ZIDOO X9S 23ZIDOO X9S android 6.0 TV box 1ZIDOO X9S android 6.0 tv box 3ZIDOO X9S android 6.0 tv box 4ZIDOO X9S android 6.0 2
